Heat Recovery Ventilator
The heat recovery ventilator is a energy-saving ventilation solution, introducing fresh air into rooms to help you breathe easy at anytime.
Airflow System
Energy Saving Analysis
Summer Energy Saving Analysis
In summer operation, when the cold energy of 27℃ air discharged from indoor pass through the heat exchanger, the 35℃ outdoor hot air is pre-cooled to 29.4℃ fresh air and supplied to indoors, as shown above, the air conditioner only needs to cool the air by 2.4℃ to maintain a comfortable room temperature and fresh air. In this process, the discharge air pre-cools the fresh air by HRV, The temperature recovery efficiency in cooling is 70% max, and enthalpy exchange efficiency is 57% max.
Winter Energy Saving Analysis
In winter operation, when the heat energy of 21℃ air discharged from indoor pass through the heat exchanger, the 5℃ outdoor cold air is pre-heated to 17℃ fresh air and supplied to indoors, as shown above, when outdoor 5℃ air and indoor 21℃ air pass through the HRV, the fresh air supplied to indoors is about 17℃, the air conditioner only needs to heat the air by 4℃ to maintain a comfortable room temperature and fresh air. The temperature recovery efficiency in heating is 75% max, and enthalpy exchange efficiency is 63% max. Heat Recovery Ventilator Lineup
